Exceptional
balance and smooth, easy handling make Beretta Over-and-Unders the
favorites of hunters worldwide.
The Silver
Essential-Beretta's basic over-and-under. Here's
a functional, working gun for the serious hunter. It's a no-frills
shotgun with all the operating systems and safety features that
make a Beretta, a Beretta. The straight-grained stock is selected
for strength and durability and highlighted with clean, cut checkering
on the pistol grip and fore-end. The low profile receiver and slim
fore-end enhance pointability. Bores and chambers are chrome-lined
for extra durability. The open side rib design results in a faster
swing, light weight and faster cooling.Long life and durability
are assured by the perfect mating of Monobloc and barrels, self
adjusting, dual conical locking lugs and strong, replaceable hinge
pins.
|
The receiver is finished for extra durability and corrosion resistance
with brushed chrome, while barrels are finished in matte black.The
tough stock and fore-end are made to stand up to years of abuse
in wet duck blinds or dry, dusty days afield. The Silver Essential
is chambered for all 2-3/4 inch and 3 inch shells. It is available
in 12 gauge with 26 inch or 28 inch barrels. Feature for feature,
the Silver Essential is an unbeatable value
The
S686 Onyx- a hunting partner with a classic look.
The ventilated rib, barrels and receiver of the Beretta Onyx are
semi-matte satin finished to eliminate reflection and glare in
the field. Inside, bores and chambers are fully chromed for unmatched
durability and corrosion resistance. Its low profile closed receiver
provides the balance and pointability that are distinctively Beretta.
The 12 gauge Onyx chambered for 3-1/2 shells is specially designed
to help you bag turkey and waterfowl. The stock and fore-end are
cut checkered and made of American walnut. The semi-beavertail
style fore-end features finger grooves for an instinctive hand
hold and improved grip. The top of the receiver is embellished
with coined scalloped fences. Gold accents the trigger, and a
gold-filled "P. Beretta" signature highlights the receiver. A
grip cap adds a stylish statement. Available in 12 and 20 gauge.

|
| Silver
Essential & Onyx Over-and-Under Specifications |
| Model |
Gauge |
Chamber
(mm/in) |
Chokes |
Barrel
Length (cm/in) |
Overall
Length (cm/in)** |
Average
Weight (Kg/Lbs)°° |
Stock
Drop Comb (mm/in) |
Heel |
Length
of Pull (mm/in) |
| 67/26 |
71/28 |
75/30 |
| Silver
Essential |
12 |
76/3 |
MC |
. |
. |
|
116/45.7 |
3.05/6.7 |
35/1.4 |
55/2.2 |
368/14.5 |
| S686
Onyx |
12 |
89/3
1/2 |
MC |
. |
. |
. |
116/45.7 |
3.15/6.9 |
35/1.4 |
55/2.2 |
368/14.5 |
| S686
Onyx |
12 |
76/3 |
MC |
. |
. |
. |
116/45.7 |
3.10/6.8 |
35/1.4 |
55/2.2 |
368/14.5 |
| S686
Onyx |
20 |
76/3 |
MC |
. |
. |
|
116/45.7 |
2.80/6.2 |
35/1.4 |
55/2.2 |
368/14.5 |
| All
models equipped with ventilated, field type (6mm)rib.*MC- Mobilchoke®
tubes standard. Fixed chokes available on request.° Indicates
optional barrel lengths available on request.°° Overall
length based on 28" barrel unless shotgun unless otherwise specified.**
Weights are approximate, dependent on wood density and barrel length. |
| Mobilchoke®
System Mobilchoke®
screw-in choke tubes are made of high-grade steel with a nickel-plated
finish for corrosion resistance and durability. They are fully interchangeable
between all Beretta Semi-Automatic and Over-and-Under shotguns.
The locking wedge design ensures that the taper on the base of the
choke tube locks into the taper of the barrel to provide a positive
gas seal and a safe lock-up of choke to barrel. Fitting flush with
the end of the barrel, Mobilchoke® tubes are steel-proofed to
withstand the rigors of non-toxic steel shot. The conical parallel
design, with the choke tapering and running parallel out to the
muzzle end, improves pattern uniformity and density. Their long
length creates a more gradual taper inside the choke tube, resulting
in reduced shot deformation and better patterns because of improved
uniformity and increased pattern density.
Extra
long choke tubes are available and are designed
to fit both single-barrel and double-barrel shotguns. Extending
1 inch beyond the muzzle and measuring 3 inches overall, their
longer, tapered shape enhances shot patterns by providing better
support of the shot column and less pellet deformation. The knurled
extension on the tube allows for easy removal and replacement
by hand, without tools. The trapezoidal threading system, with
its steeply pitched threads, allows for fast, easy installation
and removal, while preventing the choke from seizing in the barrel.
A convenient, user-friendly wrench is supplied with the Mobilchoke®
system.
| Fixed
Chokes & Beretta's Mobilchoke® Designations |
Choke
Designation |
Standard
Markings |
Mobilchoke®
Rim
Notches |
Designation
for Mobilchoke®
Compatibility
with Steel Shot* |
Extra
Long Tube |
| Full |
F |
0 (*) |
I |
SP(¹) |
. |
| Improved
Modifield |
IM |
00 (**) |
II |
SP(¹) |
. |
| Modifield |
M |
000 (***) |
III |
SP |
. |
| Improved
Cylinder |
IC |
0000
(****) |
IIII |
SP |
. |
| Cylinder |
CL |
C0000
(C****) |
IIIII |
SP |
. |
| Skeet(2) |
SK |
SK
(Skeet Beretta) |
No Notches |
SP |
. |
| *The
use of steel shot cartridges is not recomended in both over-and-under
and side-by-side shotguns with fixed chokes. (¹) Full
choke constriction when utilizing steel shot does not increase
pattern density associated with lead. (2) Special Beretta
skeet choke with negative value. Mobilchoke®
is a register trademark of Fabbrica D'Armi Pietro Beretta,
S.p.A. |
|
|
